Optimized for performance, endurance, and reliability, enterprise-class SandForce® flash controllers enable solid state drives for I/O intensive business applications and hyperscale datacenters.

  • Powerful flash media error correction (ECC) and RAISE™ technology significantly improve drive reliability
  • Balanced read/write speeds maximize the throughput of a SATA 6 Gb/s interface, keeping the enterprise-class system performance highly effective

SF2600 & SF2500 Product Brief >

Enterprise Flash Controller

SF2600 & SF2500: Reliable, High-performance Solutions for Most Demanding Applications

  • Accelerate solid state drive performance in I/O intensive enterprise applications
  • Ensure critical operations with power failure protection that completes pending writes to flash in emergencies
  • Maximize endurance and longevity with DuraWrite™ data reduction technology that minimizes writes to flash memory
  • Protect critical data with high-level security protocols and automated hardware encryption
  • Provide high data reliability with enhanced ECC and RAISE data protection technology

Enterprise Flash Controller

SF3700: Build Robust PCIe and SATA Flash Storage for Enterprise Applications

  • Support native PCIe® Gen2 and SATA 6 Gb/s host interfaces in a single design for a greater manufacturing flexibility, and lower cost
  • Ensures that pending writes to flash are completed in the event of power loss with power failure protection
  • Provide high data reliability with SHIELD™ advanced error correction that further extends flash memory life by implementing a low-density parity check (LDPC) algorithm that combines hard-decision, soft-decision, DSP and adaptive ECC
  • Deliver enhanced RAISE technology that includes new levels of data protection and additional redundancy for mission critical enterprise solutions ensuring access to data even after a page, block, or full die fault

IOPS (sustained)
Host Interface
Max Capacity Supported
Data Encryption
Data Protection
Power Fail Protection
Flash Memory Support
Sequential read and write transfer
Random read and write IOPS
Reliability: ECC recovery
Reliability: Unrecoverable read errors
Package
DuraClass Technology
  • SF2600 Flash Controller
    SF-2682VB1-SCC
  • Data Sheet
  • SF2500 Flash Controller
    SF-2582VB1-ICB
  • Data Sheet
  • SF2600 Flash Controller
    SF-2682VB1-ICB
  • Data Sheet
  • SF2500 Flash Controller
    SF-2582VB4-SCC
  • Data Sheet
  • SF2500 Flash Controller
    SF-2581VB4-SDC
  • Data Sheet
Up to 60,000 Up to 60,000 Up to 60,000 Up to 60,000 Up to 60,000
SATA 6 Gb/s, 3 Gb/s, and 1.5 Gb/s support. SATA 6 Gb/s, 3 Gb/s, and 1.5 Gb/s support. SATA 6 Gb/s, 3 Gb/s, and 1.5 Gb/s support. SATA 6 Gb/s, 3 Gb/s, and 1.5 Gb/s support. SATA 6 Gb/s, 3 Gb/s, and 1.5 Gb/s support.
512 GB (using 32 Gb or 64 Gb/die components 512 GB (using 32 Gb or 64 Gb/die components 512 GB (using 32 Gb or 64 Gb/die components 512 GB (using 32 Gb or 64 Gb/die components 512 GB (using 32 Gb or 64 Gb/die components
AES-256 & AES-128, TCG Enterprise (optional add-on feature) AES-256 & AES-128, TCG Enterprise (optional add-on feature) AES-256 & AES-128, TCG Enterprise (optional add-on feature) AES-256 & AES-128, TCG Enterprise (optional add-on feature) AES-256 & AES-128, TCG Enterprise (optional add-on feature)
MLC, eMLC, and SLC; 19 nm, 20 nm-class and 30 nm-class MLC, eMLC, and SLC; 19 nm, 20 nm-class and 30 nm-class MLC, eMLC, and SLC; 19 nm, 20 nm-class and 30 nm-class MLC, eMLC, and SLC; 19 nm, 20 nm-class and 30 nm-class MLC, eMLC, and SLC; 19 nm, 20 nm-class and 30 nm-class
Up to 500 MB/s (@ 128 KB blocks) Up to 500 MB/s (@ 128 KB blocks) Up to 500 MB/s (@ 128 KB blocks) Up to 500 MB/s (@ 128 KB blocks) Up to 500 MB/s (@ 128 KB blocks)
Up to 60,000 (@ 4 KB blocks) Up to 60,000 (@ 4 KB blocks) Up to 60,000 (@ 4 KB blocks) Up to 60,000 (@ 4 KB blocks) Up to 60,000 (@ 4 KB blocks)
Up to 55 bits correctable per 512-byte sector (BCH) Up to 55 bits correctable per 512-byte sector (BCH) Up to 55 bits correctable per 512-byte sector (BCH) Up to 55 bits correctable per 512-byte sector (BCH) Up to 55 bits correctable per 512-byte sector (BCH)
Less than 1 sector per 1017 bits read Less than 1 sector per 1017 bits read Less than 1 sector per 1017 bits read Less than 1 sector per 1017 bits read Less than 1 sector per 1017 bits read
400-pin TFBGA – 14 x 14 mm, 0.65 mm pitch, 16 byte lanes 400-pin TFBGA – 14 x 14 mm, 0.65 mm pitch, 16 byte lanes 400-pin TFBGA – 14 x 14 mm, 0.65 mm pitch, 16 byte lanes 400-pin TFBGA – 14 x 14 mm, 0.65 mm pitch, 16 byte lanes 400-pin TFBGA – 14 x 14 mm, 0.65 mm pitch, 16 byte lanes
DuraWrite extends the endurance of SSDs
Intelligent block management and wear leveling
Intelligent read disturb management
Intelligent “recycling” for advanced free space
management (garbage collection)
RAISE (Redundant Array of Independent Silicon Elements)
Intelligent data retention optimization
Best-in-class ECC protection for longest data retention and drive life
Power/performance balancing
Thermal threshold management

Driven to Perform

Products with the SandForce Driven® logo incorporate a SandForce® flash controller with award-winning DuraClass™ technology. The SandForce Driven logo signifies the best-in-class SSD reliability, performance, and power efficiency that differentiate SandForce-based SSDs from other standard SSD products. Make sure you’re using the best – make sure your equipment is SandForce Driven!
