Reliable, High Capacity Video HDD Performance

Seagate® Video 3.5 HDDs are designed to deliver reliable 24×7 operation— optimized for low-power consumption, quiet operation, smooth video streaming, high reliability and high capacity.

  • Reliably delivers up to 16 simultaneous streams of HD content
  • The world’s first 4TB video storage solution—enough storage for up to 480 hours of HD video content
  • Quiet operation to enhance customer viewing and listening experiences
  • Industry-leading reliability
  • 24×7 operational profile to meet the always-on demands on the DVR market

Always on, always reliable DVR storage.

Media technology demands both reliability and energy efficiency. Seagate® Video 3.5 HDDs deliver some of the industry’s lowest overall power consumption profiles, coolest operating temperatures and best AFRs.

Low-power profiles help DVR manufacturers achieve reduced overall power requirements and support Energy Star compliance.



More Video 3.5 HDD features

Performance and low-power consumption.

Video 3.5 HDDs meet the rising demand for energy-conserving consumer electronics without compromising performance.

Seagate is committed to environmental stewardship that goes well beyond reduced power consumption. In fact, the Video 3.5 HDD is a value proposition for sustainability by design.

More Video 3.5 HDD features

Up to 480 hours of HD content with 4TB of capacity.

Introducing the world’s first 4TB drive built specifically for video applications. Video 3.5 HDDs meet the growing demand for more storage in DVR and media center applications with support for up to 16 HD streams. Capturing, storing and viewing up to 480 hours of your favorite video content has never been easier.

More Video 3.5 HDD features

Do More

High-Capacity Storage Readiness

Enabling key elements for hard drive capacities over 2.1TB

More
Related products
Video 2.5 HDD
Video 2.5 HDD

Cool, quiet, low power video performance.

sv35-main
SV35 Series Hard Drive

Cost-effective 1TB, 2TB, 3TB Surveillance HDD capacitites.

Constellation ES
Enterprise Capacity 3.5 HDD

File server and JBOD/RAID storage systems. SED, ISE and FIPS options.

Features

Delivers 24×7 reliability.

With an AFR of 0.55%, Seagate® Video 3.5 HDD feature industry-leading reliability for always-on devices such as DVRs and home cinema systems.

And Video 3.5 HDDs can take the heat in the most demanding 24×7 systems. This hard drive improves reliability with the capability of operating at temperatures of up to 75ºC. Key to Video 3.5 HDDs remarkable reliability is the reduced heat output because of its low power consumption.

Seagate Video 3.5 HDDs feature:

  • One of the industry’s lowest overall power consumption profiles
  • Up to 40% less heat produced than comparable drives during similar duty cycles

Seagate and sustainability.

Video 3.5 HDDs are designed with a proactive approach to sustainability and environmental stewardship.

  • Up to 50% of the materials used to manufacture Video 3.5 HDDs come from recycled sources
  • Up to 70% of the drive’s materials are recyclable
  • Meets all RoHS and new REACH standards
  • Low halogen use

High capacity, hours of video.

Introducing the Video 3.5 HDD, the world’s first 4TB video-optimized hard drive. Customize storage needs with capacities ranging from 250GB to 4TB, from 30 to 480 hours of HD recording.

Resources

Specifications


Capacity 4TB 3TB 2TB 1TB 500GB 320GB 250GB
Show me :
Form Factor 3.5" 3.5" 3.5" 3.5" 3.5" 3.5" 3.5"
Interface Options SATA 6Gb/s SATA 6Gb/s SATA 3Gb/s SATA 3Gb/s SATA 3Gb/s SATA 3Gb/s SATA 3Gb/s
Performance
Spindle Speed (RPM) 5900 5900 5900 5900 5900 5900 5900
Cache (MB) 64 64 64 64 8 8 8
Transfer Rate, Max Ext (MB/s) 600 600
Sustained Data Rate OD 180Mb/s 180Mb/s 144MB/s 159MB/s
Average Latency (ms)     5.1 5.1
Power Management
Seek, Typical Operating (W) 6.0 6.0 4.5 4.5
Idle, Typical Operating (W) 3.0 3.0   0.145
Environmental
Temperature
Operating 0° to 75°C 0° to 75°C 0° to 75°C 0° to 75°C
Non-operating -40° to 70°C -40° to 70°C -40° to 70°C -40° to 70°C
Shock
Operating: Gs (ms) 80 (2ms) 80 (2ms) 80 (2ms) 80 (2ms) 70 (2ms) 70 (2ms) 70 (2ms)
Non-operating: Gs (ms) 300 (2ms) 300 (2ms) 300 (2ms) 350 (2ms) 350 (2ms) 350 (2ms) 350 (2ms)
Acoustics (bels - sound power)
Idle 2.3 2.3 2.0 1.9
Operating 2.4 2.4 2.2 2.2
Physical
Height (in/mm) 1.028/26.1 1.028/26.10 1.028/26.1 0.795/20.20 0.795/20.20 0.798/20.20 0.798/20.20
Width (in/mm) 4.010/101.85 4.010/101.85 4.0/101.6 4.0/101.6 4.010/101.85 4.010/101.85 4.010/101.85
Length (in/mm) 5.787/147.00 5.787/147.00 5.78/147.00 5.78/147.00 5.787/146.99 5.787/146.99 5.787/146.99
Weight (lb/g) 1.44/650 1.44/650 1.39/635 0.915/415 0.926/420 0.926/420 0.871/395
Model Number Capacity Interface Spindle Speed (RPM) Cache (MB) Maximum Operating Shock Storage Type Length Width Height Typical Weight AFR Average Operating Power
ST4000VM000 4TB SATA 6Gb/s 5900RPM 64MB 80Gs   147.00mm 101.85mm 26.1mm 650g 0.55%
ST3000VM002 3TB SATA 6Gb/s 5900RPM 64MB 80Gs   147.00mm 101.85mm 26.10mm 650g 0.55%
ST2000VM002 2TB SATA 3Gb/s 5900RPM 64MB 80Gs   147.00mm 101.6mm 26.1mm 635g 0.55%
ST1000VM002 1TB SATA 3Gb/s 5900RPM 64MB 80Gs   147.00mm 101.6mm 20.20mm 415g 0.55% 0.145W
ST3500312CS 500GB SATA 3Gb/s 5900RPM 8MB 70Gs   146.99mm 101.85mm 20.20mm 420g 0.55%
ST3320311CS 320GB SATA 3Gb/s 5900RPM 8MB 70Gs   146.99mm 101.85mm 20.20mm 420g 0.55%
ST3250312CS 250GB SATA 3Gb/s 5900RPM 8MB 70Gs   146.99mm 101.85mm 20.20mm 395g 0.55%
