Specs

Model	Data Sheet	User Manual	Capacity
Business Storage 4-Bay Rackmount NAS 0TB/enclosure STDN100			0TB
Business Storage 4-bay Rackmount NAS 4TB STDN4000100			4TB4096.0
Business Storage 4-bay Rackmount NAS 8TB STDN8000100			8TB8192.0
Business Storage 4-bay Rackmount NAS 12TB STDN12000100			12TB12288.0
Business Storage 4-bay Rackmount NAS 16TB STDN16000100			16TB16384.0

Interface	Ethernet
Width	381mm
Length	430mm
Typical Weight	9.065kg
Operating System	Seagate® NAS OS(embedded Linux)
Number of Drive Bays	4 hot-swappable 3.5-inch SATA II/SATA III
Memory	2GB DDR III
Processor	Dual-core 2.13GHz Intel® 64-bit Atom™ processor
Networking	Two (2) 10/100/1000 Base-TX (Gigabit Ethernet)
External Ports	Two (2) USB 3.0 (rear) Two (2) USB 2.0 (rear) One (1) eSATA (rear) One (1) USB 2.0 (front)
Hard Drive Capacity	Seagate NAS HDD 2TB, 3TB, 4TB for preconfigured models
Total capacity	4TB, 8TB, 12TB, 16TB
Certified Drives List	3.5-inch SATA II or SATA III (see NAS Certified Drive list PDF for more details)
Power	100V to 240V AC, 50/60Hz, 180W
Power Supply and Power Management	Sleep mode for power saving Scheduled power on/off Wake-on-LAN
Cooling Management	Two (2) fans
Transfer Rate	200MB/s reads and writes¹
Network Protocols and Services	CIFS/SMB, NFS v3, AFP, HTTP(s), FTP, sFTP, iSCSI, Print serve, failover and load balancing (LACP 802.3ad), Wuala file system integration (W:/ network drive), Active Directory™
Certifications	VMware Ready
RAID	RAID 0, 1, 5, 6, 10 Hot spare SimplyRAID™ technology with mixed capacity support, volume expansion and migration
Management	Web-based interface through http/https Hardware monitoring (S.M.A.R.T., casing cooling and temperature, CPU and RAM load) Log management and email notification NAS OS Installer for diskless setup, data recovery and restore to factory settings Product discovery with Seagate Network Assistant
Media Streaming	UPnP DLNA A/V media adapter-compatible Photo browser and audio streaming through Web interface iTunes™ (DAAP) server
Backup Solution	PC to NAS: using client software (Time Machine™, Windows® Backup, etc.) NAS to DAS: scheduled, automatic and restore NAS to NAS: scheduled, encrypted, compressed, and automatic to local or remote NAS
Remote access	Web-based Android and iOS app Wuala Secure Cloud Service: Manage cloud, remote and local storage from a single interface; secure remote access from PC, Mac, iOS, Android
Client OS Supported	Windows 8 (32-bit/64-bit) Windows 7 (32-bit/64-bit) Windows Vista (32-bit/64-bit) Windows XP Windows Server 2012 Windows Server 2008 R2 Windows Server 2008 Mac OS 10.6 and later
Browser supported	Latest version of Chrome, Firefox and Safari; Internet Explorer 8, 9 and 10
Language	English, Spanish, German, French, Italian, Dutch, Chinese Traditional, Chinese Simplified, Korean, Portuguese, Russian
Drive Configurations	4TB (2x2TB), 8TB (4x2TB), 12TB (4x3TB), 16TB (4x4TB)
